Thermoplastic IP66 Pilot Acting Solenoid Valve

  • ALV series high performance NAMUR solenoid valve is specially designed for the outdoor use of pneumatic actuator, using advanced cartridge structure sealing technology, the valve body has no breathing hole to outside, good waterproof and dust-proof performance and long working life. Each valve body is equipped with 3/2 and 5/2 NAMUR plates that is available for the operation of double-acting and spring-return pneumatic actuators. The solenoid valve is equipped with external tight waterproof cable connector, and the climate protection level reaches to IP66.

Approved By:
